Is my wound infected? New pocket-sized device for clinicians could spot infected wounds faster

Scientists have developed a device that works with a smartphone or tablet to capture medical images which can identify infected wounds.

By Angharad Brewer Gillham

The medical model could accurately predict all three wound classes (infected, inflamed, and non-infected) with an accuracy of 74%. Credit: Image generated by DALL-E 2 from Microsoft Bing

By capturing the heat produced by a wound and the fluorescence of bacteria, it helps clinicians tell the difference between inflammation and a potentially dangerous infection. This could allow for quicker intervention, catching infections before they become serious threats to health.

It’s notoriously difficult for doctors to identify a wound that is becoming infected. Clinical signs and symptoms are imprecise and methods of identifying bacteria can be time-consuming and inaccessible, so a diagnosis can be subjective and dependent on clinician experience. But infection can stall healing or spread into the body if it isn’t treated quickly, putting a patient’s health in grave danger. An international team of scientists and clinicians thinks they have the solution: a device run from a smartphone or tablet app which allows advanced imaging of a wound to identify infection.

“Wound care is one of today’s most expensive and overlooked threats to patientsand our overall healthcare system,” said Robert Fraser of Western University and Swift Medical Inc, corresponding author of the study published in Frontiers in Medicine. “Clinicians need better tools and data to best serve their patients who are unnecessarily suffering.”

Shedding light on injuries.

The scientists developed a device called the Swift Ray 1 which can be attached to a smartphone and connected to the Swift Skin and Wound software. This can take medical-grade photographs, infrared thermography images (which measure body heat), and bacterial fluorescence images (which reveal bacteria using violet light).

None of these images would be enough to identify infection alone. Clinical inspection has low accuracy, as does thermography measuring heat changes caused by inflammation and infection. Bacterial fluorescence can only look at the surface of a wound, which is naturally contaminated with bacteria, so additional methods are needed to differentiate between contamination and an infected wound.

“Research has demonstrated bacterial imaging helps guide clinicians’ work to remove nonviable tissue, yet it cannot identify infection by itself,” explained Dr Jose Ramirez-GarciaLuna of McGill University Health Centre, first author of the study. “Thermography provides insight into the inflammatory and circulatory changes happening under the skin.”

The Ray 1 hyperspectral imaging device. The Ray 1 imaging device is a pocket-sized hyperspectral camera that is designed to sit over a smartphone's camera lens and wirelessly connect to Swift Medical's Skin and Wound app. Once connected, the camera allows the simultaneous acquisition of: visible light images that can be used for clinical inspection, wound area measurement, and the automated identification of tissue types present in the wound; infrared thermal images for the assessment of vascular and inflammatory patterns; and bacterial fluorescence images for the assessment of bacterial bioload in wounds, such as in the vignette presented at the bottom of the figure.

The scientists sought to combine these modalities to come up with a method which wouldn’t need multiple expensive devices, would overcome the weaknesses of each imaging method, and could provide an objective measure of wound healing.

To test their device, they recruited 66 wounded patients. Their wounds showed no sign of infection spreading further, did not contain foreign bodies, and had not previously been treated with antibiotics or growth factors. The patients’ wounds were uncovered, cleaned, and dried before imaging, and afterwards cared for as usual.

Non-inflamed, inflamed, infected.

The images were reviewed by a researcher who wasn’t present for the wound care process. Four patterns were identified. Wounds where the wound was not warmer than healthy skin and no bacterial fluorescence was present were considered non-inflamed, while wounds that were slightly warmer than healthy skin and had no or slight bacterial fluorescence were considered inflamed. The last two patterns — wounds that were substantially warmer, with or without bacterial fluorescence — were both designated as infected, because all the clinicians who had examined these wounds had considered them infected.

Out of the 66 wounds, 20 were considered non-inflamed, 26 were inflamed, and 20 were infected.

The researchers performed principal component analysis and used an algorithm called nearest k-neighbor clustering to see if a machine learning model could accurately identify these different categories of wound. They found that the model could identify all three very well, with an overall accuracy of 74%. When differentiating between infected vs. non-infected wounds, the model correctly identified 100% of infected wounds and 91% of non-infected wounds.

A new tool in the box.

The researchers pointed out that the images should always be considered in their medical context. For instance, a wound that is cool enough to be categorized as non-inflamed could have a limited blood supply, compromising healing. But because the Swift Ray 1 combined with the Swift Skin and Wound software allows doctors to combine multiple modalities of identifying infection, it increases the tools available to them without demanding the use of several expensive devices. In the future it could make it possible to secure a rapid, accurate diagnosis for every wounded patient and enable more effective telemedicine assessments.

“This was a pilot study and follow up studies are planned,” cautioned Fraser. “In the future, patient populations with more wound types are required to validate across populations.”

• Provided by Frontiers

• Reference: Jose L. Ramirez-GarciaLuna, Mario A. Martinez-Jimenez, Robert D. J. Fraser, Robert Bartlett, Amy Lorincz, Zheng Liu, Gennadi Saiko, Gregory K. Berry. Is my wound infected? A study on the use of hyperspectral imaging to assess wound infection. Frontiers in Medicine (2023). DOI: https://doi.org/10.3389/fmed.2023.1165281
